industrial mixer machine milk powder blend machine mixer for milk
W type mixer, high efficient mixer, is commonly-used mixer machine for dried powder or granules mixing on the international market.
Feature:
simple structure, easy operation, cleaning and maintenance convenience, fast mixing speed and good mixing effect
Models&Technical Data
Model | BSW-180 | BSW-300 | BSW-500 | BSW-1000 | BSW-1500 | BSW-2000 | BSW-2500 | BSW-3000 | BSW-4000 |
Full volume(m3) | 0.18 | 0.3 | 0.5 | 1.0 | 1.5 | 2.0 | 2.5 | 3.0 | 4.0 |
Mixing time(min) | 4-8 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 | 6-10 |
Turning speed of cylinder(rpm) | 12 | 12 | 12 | 12 | 12 | 12 | 12 | 7.8 | 7.8 |
Power(kw) | 1.1 | 1.1 | 2.2 | 4 | 4 | 7.5 | 7.5 | 7.5 | 11 |
Overall size of Main frame(L×W×H)(mm) | 1400× 800×1850 | 1685× 800×1850 | 1910× 800×1940 | 2765× 1500×2370 | 2960× 1500×2480 | 3386× 1900×3560 | 3386× 1900×3560 | 4450× 2200×3600 | 4750× 2500×3680 |
Gross rotation height(mm) | 1850 | 1850 | 1950 | 2460 | 2540 | 3650 | 3650 | 3700 | 3730 |
Weight(kg) | 280 | 310 | 550 | 810 | 980 | 2150 | 2150 | 2500 | 3200 |
Main Features
1) High mixing efficiency.
2)Free of dead corner.
3) even mixing.
4) Safty bar can be added.
5) Forced agitator can be added.
1) With safety bar, mixer can work when safety bar is in horizontal position.
When safety bar is upward turned, power will be cut automatically and mixer is stopped.
This function will protect operator from possible injury from the rotating V mixing barrel.
2)With auto-positioning stop function, when machine stops, the discharge parts is
right towards the ground automatically, no need to use point-stop (jog)manually.
3) With intensifier bar (agitator) inside mixer, mixing effect will be better; when mix powder which is a little sticky or bad fluidity, this is high recommened to add.
Brightsail Industries Group Co.,Ltd. is the trade dept of Jiangyin Brightsail Machinery Co.,Ltd and Jiangyin Heng Sheng Steel Structure Co.Ltd which is established in 2002.
We provide professional powder processing overall solution,grinder,mixer,sifter,welding service,welding machine,chemical powder...etc.
We have sent our products to more than 40 countries around the world for now.Brightsail is constantly committed to develop new advanced techniques and methods on the machines,since our goal is to be your trusted provider of creative and value added process solutions.
Our grinder machine has been certified by European Conformity and International Organization for Standardization. So about machine quality, you do not have to feel worried.
1. Pre-sales service:
Inquiry and consulting support with 24 hours;
Machine sample test service;
Factory visit
2. After-sales service:
Instructing how to install and use the machine;
one year warranty;
video support;
engineer is available to go to user's factory to help install and train.
